550ML Cap IML Mould
SINO MOULD Professional 550ml cap IML injection mould with 4/8/16 cavity options, reverse gating, precise cooling system and side-entry manipulator labeling. High-precision food-grade mold for ice cream, yogurt and fermented milk cup lids with stable mass production, no label peeling and low-temperature resistance.
Standard 550ml Cap IML Mould Details
Below are examples of the most common parameters for 550ml Cap IML Mould.
| 550ml Cap IML Mould Cavity Steel | S136 / H13 | Recommended Injection Machine | DKM310DFS/DKM360DFS |
|---|---|---|---|
| 550ml Cap IML Mould Core Steel | S136 /H13 | Plastic Material | PP |
| Mould Base Standard / Steel | 4Cr13 Pre-hardened Stainless Steel/P20 | Ejection System | Stripper, Air valve |
| Air valve,stripper | High-strength tool steel with surface hardening treatment | Injection Process | High-speed injection, short cycle time, precise temperature control |
| Number of Cavities | 2/4/8/16 cavities | Injection Cycle Time | 6-8 seconds |
| Hot Runner System | Fully hot runner system | Mould Manufacturing Lead Time | 65-75 working days |
Key Quality Points of 550ml Cap IML Mould
- Reverse injection gate structure, suitable for IML labeling characteristics
- Precise control of the gate cooling system
- Fixed mold side positioning + Side-in type manipulator adaptation
Precision Machining Highlights for 550ml Cap IML Mould
- CNC precision carving and mirror polishing of the cavity, without knife marks, pockmarks, or scratches;
- The dimensional error of each cavity in the multi cavity mold is ≤ 0.02mm, and the product weight is uniform and consistent.
