Washing Machine Mould
SINOMOULD is a professional manufacturer of Washing Machine Mould and plastic home appliance Mould, providing high-precision, durable and efficient Mould solutions for home appliance enterprises worldwide. Our Washing Machine Mould adopts advanced processing technology and high-quality steel materials to meet the mass production needs of washing machine plastic parts.
Washing Machine Mould Detail
Below are examples of the most common parameters for Washing Machine Mould.
Mould Name | Washing Machine Mold | Product Size | 700x400x186mm |
Product Description | Washing machine cover | Mould Cavity | 1 cavity |
Mould Size | 1150x850x680mm | Suitable Machine | DKM550SV |
Mould Cavity/Core Steel | 718H | Mould Base Steel | SINO Standard |
Mould Injection System | 4 tip Anole hot runner | Mould Ejection System | Ejector pin |
Mould Injection Process | High-gloss injection moulding | Cycle Time | 72s |
Delivery time | 75 working days |
|
|
Washing Machine Mould Quality Points
- Steel material selection: We strictly select high-quality steel materials (718H, S136, H13, etc.) for Washing Machine Mould, which have excellent wear resistance, corrosion resistance and toughness, ensuring the service life of the mould reaches 500,000-1,000,000 shots.
- lPrecision control: The mould processing accuracy is controlled within ±0.005mm, adopting high-precision CNC machining, EDM and WEDM technologies to ensure the size and surface quality of plastic parts meet the requirements of washing machine production.
- lQuality inspection: Every link of mould manufacturing is subject to strict inspection, including raw material inspection, processing precision inspection, assembly inspection and test run inspection, to eliminate unqualified products.
- lSealing performance: The mould parting surface is precisely ground to ensure good sealing performance, avoiding flash and burrs of plastic parts, and improving the qualified rate of products. As a professional plastic home appliance mould manufacturer, we always take quality as the core to create reliable Washing Machine Mould for customers.
Washing Machine Mould Processing Points
- Mould design: Combine the structure of washing machine plastic parts and production needs, optimize the mould structure through 3D design, avoid structural defects such as undercut and difficult demoulding, and improve production efficiency.
- lProcessing equipment: Use advanced processing equipment such as high-speed CNC milling machines, EDM machines and WEDM machines to ensure the processing precision and surface finish of the mould.
- lHeat treatment: The mould parts are subjected to professional heat treatment (quenching, tempering, etc.) to improve the hardness and wear resistance of the parts, extending the service life of the mould.
- lAssembly process: The assembly of the mould is carried out by professional technicians, strictly following the assembly process, ensuring the coordination of each part, smooth operation of the mould and stable demoulding.
- lTest run adjustment: After the mould is assembled, conduct test run adjustment, optimize the injection parameters, ensure the plastic parts are formed perfectly, and meet the customer’s production requirements. Our processing team has rich experience in plastic home appliance mould manufacturing, and can provide professional processing services for Washing Machine Mould.
